New Products
Low Maintenance, Quick- Change Jaw Chuck Up- graded
—Schunk
Schunk’s Rota THW3 quick-change jaw chuck is designed for short set-up times and low maintenance. The lathe chuck with the patented sealing system reportedly accelerates the jaw change on CNC lathes, pick-up lathes and turning-milling centers, while at the same time providing jaw change repeatability up to <0.02 mm. This means that jaw sets that have been turned out once can be used repeatedly, even with demanding tolerances.
The jaw stroke of the straight toothed base jaws is 6.7 mm to 10.5
mm, depending on the size. A ring piston with a direct power transmis- sion is said to ensure a high degree of efficiency, and in the smallest size, 200, the chuck already achieves a clamping force of 64 kN; from size 400 it is 240 kN. Its hardened and stiff base body ensures that precise and reliable ma- chining can be carried out even under maximum stress. The jaw features a large chuck bore from 52 mm (size 200) to 165 mm (size 630), protective rifles that can be exchanged from the front and the possibility of internal and external tension. There is also the op- tion of supplementing the chuck with an adjustable stop.
The Rota THW3 chuck has also been enhanced with large tool storage,
multi spindles and modular machine controls.
IBS Quality and Verisurf Software Portable Cobot Inspection System
—IBS Quality and Verisurf
IBS Quality GmbH recently launched the new PAM-System (Porta- ble Automated Measurement System), a portable cobot-based 3D scanning and measurement solution, at Control, Stuttgart, Germany. The launch is in collaboration with Verisurf Software.
The PAM-System is a portable scanning, measurement, and inspec- tion solution that uses cobots (collab-
