 New Products
 orative robots) to augment repetitive user routines while adding flexibility, dexterity, and accuracy. All hardware (including fixtures for sensor attach- ments to the robot), software, installa- tion, service, and support are included with the comprehensive system. The entire solution is self-contained on a specially designed inspection cart that can be easily rolled from the quality
3.6”
lab to the shop floor. The PAM-System can be used for first article inspection, volume production inspection, reverse engineering, and prototyping.
“We have designed the best of to- day’s robotic, scanning, measurement, and inspection automation technolo- gies into a single mobile solution; one that meets the practical needs of job shops and OEM manufacturers adapt- ing to the realities of Industry 4.0,” said Philipp Schmid, IBS Quality GmbH.
The PAM-System includes robot- ics automation from 11 Dynamics, 3D measurement, inspection, and reporting integration with Verisurf Software, and a choice of leading 3D laser scanner brands or other scanner technologies.
The integrated Verisurf 3D Scan- ning and Inspection application is built on a CAD platform and is rooted in Model-Based Definition (MBD). Inspection plans are easily created by importing any CAD model, us- ing drawings, a golden part, or key features. Inspection plans can be used across the manufacturing enterprise on any CMM, providing repeatable pro- cess control. “The Verisurf workflow enhances productivity and enables repeatable process control, which is a key tenant of QA; the automated PAM-System supports both,” said Nick Merrell, executive vice president of Verisurf.
    www.prime-tools.com
   - Carbide Inserts
- Taps
- Reamers
- Counter Bores
- Counter Sinks
- Drills
- End Mills.
- Tool Holders
- Router Bits
- Slitting Saws
- Tools for Composites
- Screws & Nuts
- Special Tools per print
- Radius to End Mills
       P: 888-308-6657
E-mail: support@prime-tools.com
 Easily and accurately cut Nitinol, Titanium, Carbide, H14, Alumina Ceramic, Quartz, Peek, Sapphire
G1, Beryllium Copper, Silicon Carbide ....anything.
• Compact and Totally Enclosed
• Kerf down to .008”
• Positional accuracy +/- .0001”
• Ultra fast speeds with high
acceleration/deceleration
• Non-thermal cutting with no material limits
• Zero backlash linear motors with Invar
linear scales
• Fanuc 31i with user-friendly HMI interface
• Cut Ferris and non-ferrous metals very
well, very accurately and very fast
• Available in 3 axis, 4 axis, 5 axis (Multi-
configurations)
To discuss the possibilities contact: HS&S Machine Tool 408.472.2436 or
info@hsands.com
       CNC WEST June/july 2022
www.CNC-West.com
73
