New Products
Blue Photon 150 mm, 225 mm and 300 mm square pallets offer quick change and adhesive workholding of complex and hard-to-hold parts. These new pallets can hold parts securely, providing increased machining access on five to six surfaces while using standardized fixturing systems already in place.
These patented grippers are inserted into new external inserts, designed specifically for the Grip Pallets. The external inserts are available for use
with small, medium, and large grip- pers. The new inserts allow for simple installation of the grippers at the re- quired height for maximum holding power. The 150 mm square pallet is available in aluminum and steel with a 52 mm pattern for a quick change receiver that will hold up to nine grip- pers. The 225 mm square pallet is available in aluminum and steel with a 96 mm pattern for a quick change re- ceiver that will hold up to 21 grippers. The 300 mm square pallet is available in aluminum with a 96 mm pattern that will hold up to 33 grippers. Each Grip Pallet includes two handles with multiple color choices and four spacers with a 25.4 mm standoff .
The adhesive workholding process involves applying proprietary Blue- Grip workholding adhesive to the grip- pers and curing through the grippers from the backside of the Grip pallet
with ultraviolet light for 60 seconds. Part removal is quick and easy with a 1⁄4 turn twist of the gripper or hot water soak. Residual adhesive is simply removed by using a handheld steamer or a hot water soak and a light
peeling action.
New 2023 Release Debut
—Verisurf Software
Verisurf Software, Inc demonstrat- ed Verisurf 2023 at Control, Stuttgart, Germany, May 3 -6. Verisurf 2023 continues to refine metrology work- flows with added features designed to reduce time and improve the efficiency of automated quality inspection and reporting, scanning, reverse engineer- ing, and tool building.
Verisurf software is built on a CAD platform and is committed to Model- Based Definition (MBD). Verisurf
Meet Micro5
A perfectly designed 5 axis High Speed Milling Center For medical device and small complex parts
- Repeatability: 0.5μm/.00002”
- Precision target: 2 μm /.00008” - Acceleration: 25 m/s2
- Capable of mirror finish
- Full Automation ready
Learn more: HS&S Machine Tool - john@hsands.com - 408.472.2436
CNC WEST June/july 2022
www.CNC-West.com
65
Work envelope is 2” x 2” x 2”
