New Products
nance requirements.
The GL 250 also features a tailstock
that is programmable and servo-driven. Position, speed and force are deter- mined directly via the Fanuc control- ler. It includes a 12-station turret with a choice of fixed tools with a Romi disk, driven tools with a VDI (Verein Deutscher Ingenieure) or BMT (base- mounted turret) disk, driven tools with y-axis or dual spindle with driven tools and y-axis.
The CNC control features a Fanuc Oi-TF with 15” LCD touchscreen and Fanuc 32iB with 19” LCD touchscreen for dual spindle version machines and is the newest generation of FANUC’s Series iHMI.
Touch Probe Offers High Speeds and 3D Accuracy —Heidenhain
Heidenhain’s TS 760 touch probe offers 3D accuracy to within 1 μm and homogeneous switching behav- ior over 360 degrees. The company says the probe’s 1 m/min feed rate is four times faster than other prod- ucts offering repeatability equal to or within 0.25 μm at two standard deviations.
The touch probe’s low, ≈0.2 N of trigger force and ≈1.5 N of axial force limit form and surface damage to fragile parts. Users can also clean
@)
the probing point with an integrated flusher feature that uses compressed air and cooling lubricant of up to 60 bars. Functionally, the probe is fully compat- ible with the TS 740 and provides the same additional data as the TS 460.
An SE 661 transceiver with an EnDat communication signal sends collected data over radio or infrared channels to Heidenhain’s contouring TNC or other major CNC controls.
New iWire Lets Shops
Adapt to Changing EDM
Cutting Conditions
As the first of its kind in the in- dustry according to GF Machining
