New Products
GenQuick adaptors are available in ER16 to ER11 for drilling operations and in ER16 and ER20 for boring operations. All adaptors for boring operations have a locating pin for self- orienting the radial and axial positing of boring bars.
New Copy Turn Addition
—Walter
Walter has introduced the W1211/ W1210 copy turning system for boring bars. These boring bars and indexable inserts with Walter Lock (WL) posi- tive engagement successfully combat the high forces in variable directions that occur when internal profiling ap- plications with V-style (ISO-V, 35° diamond shaped) inserts according to the company.
The oblong shape of a conven-
tional V-style insert leads to a very long pocket in the boring bar to hold the V-Shaped insert. Cutting forces are encountered far away from the actual support that the insert pocket provides to withstand the cutting forces.
Walter offers two versions of these boring bars with diameters of 0.984, 1.260, and 1.575-in. W1210 for profiling angles of up to 72.5° with
a symmetric design and W1211 for profiling angles of up to 50°for a more robust support. The positive WL25 indexable inserts with three cutting edges are available in four insert types, depending on the requirements of the application: neutral, left-hand, right- hand and full-radius versions, and all fit into the same tool.
PlantMonitor to Aid Digital
Manufacturing
—HEIDENHAIN
HEIDENHAIN’s new PlantMoni- tor is a digital solution to aid the manu- facturing shop floor. Now available for companies interested in simultaneously monitoring and analyzing production data at multiple sites utilizing machine tools where at least one is equipped
