New Products
with eight cutting edges per insert. The cutters are available in two design configurations that differ in cutting edge approach angle: high feed with 12° cutting edge angle; moderate feed with 22.5° cutting edge angle. These two distinct designs (high feed, moderate feed) allow for tools to be better matched to the application/vari- ables at hand, such as machine tool and
workpiece geometry.
Another key characteristic of the
NEOFEED design is a dovetail pocket that helps ensure rigid and reliable in- sert clamping, while alleviating cutting forces on the insert screw and provid- ing the capability to withstand against the heavy loads consistent with high feed milling applications.
NanoFeedTM, Hi-Feed Per-
formance for Small Parts
—Ingersoll
Ingersoll’s new NanoFeed tech- nology provides exceptional hi-feed milling performance for machining of miniature components and smaller part features. NanoFeed is a 20° hi- feed indexable insert design that will replace smaller diameter solid carbide
end mills in many applications and offer great economy!
Inserts have been designed with pressed-in coolant channels, directing coolant or air directly to the cutting edge for maximizing tool life. Inserts also have backdraft side clearance for straight-wall milling capability. Avail- able in diameters
Grip Pallet System Addi- tion to Adhesive Work- holding Lineup
—Blue Photon
Blue Photon has expanded its prod- uct line by adding five Grip Pallets and three new inserts for 52 mm and 96 mm quick change receiver systems. The addon allows for holding more applications using existing fixturing systems in machining centers.
