New Products
type tool post for turning and cross drilling/milling for multi-processing in a new space-saving vertical layout. Simultaneously, the dynamic main spindle and faster power-driven tools are optimally designed for machining smaller diameter components. The 6-spindle unit with Y2-axis control for backworking has two spindles in three rows and can mount up to four power-driven tool units in their respective positions. This enhanced multi-processing capability in back- working contributes to reduced cycle times through the efficient splitting of processes.
With its compact body and high- performance marks, the Star CNC SL-10 represents the arrival of a new generation of machines built with integrity, stability and versatility for high efficiency processing of complex, small diameter components.
Touch Probe Offers High Speeds and 3D Accuracy —Heidenhain
Heidenhain’s TS 760 touch probe offers 3D accuracy to within 1 μm and homogeneous switching behavior over 360 degrees. The company says the probe’s 1 m/min feed rate is four times faster than other products offering repeatabil- ity equal to or within 0.25 μm at two standard deviations.
The touch probe’s low, ≈0.2 N of trigger force and ≈1.5 N of axial force limit form and surface damage to fragile parts. Users can also clean the probing point with an integrated flusher feature that uses compressed air and cooling lubricant of up to 60 bars.
@)
Functionally, the probe is fully compat- ible with the TS 740 and provides the same additional data as the TS 460.
An SE 661 transceiver with an EnDat communication signal sends collected data over radio or infrared channels to Heidenhain’s contouring TNC or other major CNC controls.
New Generation SL-10
Swiss-Type Lathe
—Star CNC
State-of-the-art small diameter parts processing is made possible by yet an- other evolution of design which debuts in the new Star CNC SL-10 Swiss-type automatic lathe.
The SL-10 utilizes a single gang
   (NEW) STENHOJ
“ Flexipress” 25-200 Ton
 Howards Machinery 714-856-2089
 Dealer Inquiries Wecome
• 15- 3/4” RAM Stroke
• Fast - Min. 26 IPM Approach
• Up to 52 IPM Return
• Machinined Surfaces
• Build Special Machines on Request
• LUX Presses to 400-ton “C FRAME”
Presses from 25 - 300 ton
   .----89,27---.
1,06
 (0176)
     72,77 02I101- 0\ 32,49
060
Premium Quick-Point Workholding
   LI ... ,,,,/
.,_ I ,89,27
@-... -

0 /I 96
 ,__-89,27---'
Contact www.synergytoolinginc.com
(6)DRILL & C'BORE FOR M12 SHCS
   TOKYO KEIKI YUKEN NACHI DAIKIN TOYO OKI REXROTH-UCHIDA SUMITOMO.
 TEL: 714-630-9111 SALES@PACIFICMACHINE.COM
 Pneumatic Hydraulic Distributor
   I’ve been helping shops with insert milling for more than 20 years
    Give me a call...
Pat Sheehan
(818) 650-1490
