New Products
Z-Mag CNC Portable Drill and Tap Machine Intro- duced
—Zagar
Zagar Inc. introduces its Z-Mag DTMTM portable CNC drill and tap machine for remote holemaking
operations. The innovation is geared toward industries such as ship build- ing, bridge construction, railroad and several others where metal removal has to be done on location due to structures that are permanently installed or too large to move. Any needed machining - like modifications, retrofitting or for final assembly needs - must be done remotely.
Zagar engineered a unique solution that uses an electromagnetic base with 5,000 lbs. of hold-down force, allow- ing users to bring precision machining to the job site. Z-Mag DTM can be used on any type of ferrous steel for drilling, tapping, reaming and even combination tooling with program- mable feeds, speeds, dwells, and peck
cycles.
The unit accommodates different
height applications with an available 13 inches of stroke, 1,300 lbf. of thrust and spindle speeds of up to 3,000. Using an HSK style spindle adapter, operators can use a variety of HSK tool holders. The sturdy cast iron frame, linear rail system, and precision ball-screw feed system provide a solid foundation for any application, from light roughing to finishing. With the use of the handheld HMI (Human Machine Interface), the operator can control the unit with touch screen controls and has the capability to program and run all operations. The unit has a servo feed motor.
Automated Multi-Sensor Video Measuring System
High accuracy, speed, and repeatability
VMA-2520/4540/6555
• Nikon’s world-renowned zoom optical system features low distortion, wide FOV, with precise edge detection and pattern recognition.
• Easy and accurate measurements optimized for 2D and 3D parts
• Multi-sensor capable with standard vision and vision auto focus. Laser auto focus and touch probe optional
• Various stage sizes and accessories available to help fit any application
52
www.CNC-West.com CNC WEST April/May 2022
Now available with AutoMeasure v. 13 software
The latest version of Nikon Metrology's dimensional measurement software for NEXIV series video measurement systems now features lighting optimization and teaching navigation.
sales.nm-us@nikon.com (800) 552-6648 www.nikonmetrology.com
Scan for More Info
VIDEO MEASURING
